Modernizing Legacy PHP Applications: From Monolith to React

At Big D Companies, I faced a challenge familiar to many developers: a legacy PHP-based ERP system managing SCADA automation that desperately needed modernization. The system worked, but maintaining it was becoming increasingly difficult, and adding new features felt like archaeology.

The Legacy Situation

The existing system was a classic PHP monolith:

Tight coupling between presentation and business logic
Limited test coverage
Performance issues from inefficient database queries
Hard to onboard new developers
MySQL database that needed to be preserved

The Migration Strategy

We couldn't do a "big bang" rewrite - the system was too critical. Instead, we took a gradual approach that allowed us to deliver value incrementally while maintaining business continuity.

Step 1: API Layer First

The first step was extracting the data layer behind a REST API. This allowed us to start building the new frontend while the old system continued running:

// api/routes/devices.js
const express = require('express');
const router = express.Router();
const mysql = require('mysql2/promise');

const pool = mysql.createPool({
  host: process.env.DB_HOST,
  user: process.env.DB_USER,
  password: process.env.DB_PASSWORD,
  database: process.env.DB_NAME,
  waitForConnections: true,
  connectionLimit: 10,
});

router.get('/devices', async (req, res) => {
  try {
    const [rows] = await pool.query(`
      SELECT
        d.id,
        d.name,
        d.type,
        d.status,
        d.last_reading,
        s.name as site_name
      FROM devices d
      LEFT JOIN sites s ON d.site_id = s.id
      WHERE d.active = 1
      ORDER BY d.name
    `);

    res.json(rows);
  } catch (error) {
    console.error('Database error:', error);
    res.status(500).json({ error: 'Internal server error' });
  }
});

router.get('/devices/:id/readings', async (req, res) => {
  const { id } = req.params;
  const { startDate, endDate } = req.query;

  try {
    const [rows] = await pool.query(`
      SELECT
        timestamp,
        temperature,
        pressure,
        flow_rate
      FROM device_readings
      WHERE device_id = ?
        AND timestamp BETWEEN ? AND ?
      ORDER BY timestamp DESC
    `, [id, startDate, endDate]);

    res.json(rows);
  } catch (error) {
    console.error('Database error:', error);
    res.status(500).json({ error: 'Internal server error' });
  }
});

module.exports = router;

Step 2: Build the React Frontend

With the API in place, we built a modern React/Next.js frontend:

// components/DeviceMonitor.tsx
import { useState, useEffect } from 'react';
import { Card, CardHeader, CardContent } from '@/components/ui/card';
import { Badge } from '@/components/ui/badge';

interface Device {
  id: number;
  name: string;
  type: string;
  status: 'online' | 'offline' | 'warning';
  last_reading: string;
  site_name: string;
}

export default function DeviceMonitor() {
  const [devices, setDevices] = useState<Device[]>([]);
  const [loading, setLoading] = useState(true);

  useEffect(() => {
    async function fetchDevices() {
      try {
        const response = await fetch('/api/devices');
        const data = await response.json();
        setDevices(data);
      } catch (error) {
        console.error('Failed to fetch devices:', error);
      } finally {
        setLoading(false);
      }
    }

    fetchDevices();

    // Poll for updates every 30 seconds
    const interval = setInterval(fetchDevices, 30000);
    return () => clearInterval(interval);
  }, []);

  if (loading) {
    return <div>Loading devices...</div>;
  }

  return (
    <div className="grid grid-cols-1 md:grid-cols-2 lg:grid-cols-3 gap-4">
      {devices.map((device) => (
        <Card key={device.id}>
          <CardHeader>
            <div className="flex justify-between items-center">
              <h3 className="font-semibold">{device.name}</h3>
              <Badge
                variant={
                  device.status === 'online' ? 'success' :
                  device.status === 'warning' ? 'warning' : 'destructive'
                }
              >
                {device.status}
              </Badge>
            </div>
          </CardHeader>
          <CardContent>
            <p className="text-sm text-gray-600">{device.site_name}</p>
            <p className="text-sm">Type: {device.type}</p>
            <p className="text-sm">
              Last Reading: {new Date(device.last_reading).toLocaleString()}
            </p>
          </CardContent>
        </Card>
      ))}
    </div>
  );
}

Step 3: Progressive Enhancement

We didn't migrate everything at once. Instead, we used a routing strategy that gradually replaced PHP pages:

// server.js
const express = require('express');
const { createProxyMiddleware } = require('http-proxy-middleware');
const next = require('next');

const dev = process.env.NODE_ENV !== 'production';
const app = next({ dev });
const handle = app.getRequestHandler();

const PORT = process.env.PORT || 3000;
const PHP_SERVER = 'http://localhost:8080';

app.prepare().then(() => {
  const server = express();

  // New React routes
  server.use('/dashboard', (req, res) => handle(req, res));
  server.use('/devices', (req, res) => handle(req, res));
  server.use('/api', (req, res) => handle(req, res));

  // Proxy everything else to PHP (legacy routes)
  server.use('*', createProxyMiddleware({
    target: PHP_SERVER,
    changeOrigin: true,
  }));

  server.listen(PORT, () => {
    console.log(`> Ready on http://localhost:${PORT}`);
  });
});

Testing Strategy

Testing legacy systems is challenging. We used Jest for new code and maintained the existing test suite:

// __tests__/DeviceMonitor.test.tsx
import { render, screen, waitFor } from '@testing-library/react';
import DeviceMonitor from '@/components/DeviceMonitor';

// Mock fetch
global.fetch = jest.fn();

describe('DeviceMonitor', () => {
  beforeEach(() => {
    (fetch as jest.Mock).mockClear();
  });

  it('displays devices after loading', async () => {
    (fetch as jest.Mock).mockResolvedValueOnce({
      json: async () => ([
        {
          id: 1,
          name: 'Pump 1',
          type: 'Centrifugal',
          status: 'online',
          last_reading: '2024-04-28T10:00:00Z',
          site_name: 'Site A'
        }
      ])
    });

    render(<DeviceMonitor />);

    await waitFor(() => {
      expect(screen.getByText('Pump 1')).toBeInTheDocument();
    });

    expect(screen.getByText('online')).toBeInTheDocument();
  });
});

Performance Improvements

The migration yielded significant performance improvements:

Database Query Optimization: Indexed queries reduced load times by 70%
Client-Side Rendering: React's virtual DOM made the UI much snappier
Code Splitting: Next.js automatically split code, reducing initial load
Caching: Implemented Redis caching for frequently accessed data

CI/CD Pipeline

We used CircleCI for automated testing and deployment:

version: 2.1

jobs:
  test:
    docker:
      - image: circleci/node:16
      - image: circleci/mysql:8.0
        environment:
          MYSQL_ROOT_PASSWORD: testpass
          MYSQL_DATABASE: test_db
    steps:
      - checkout
      - restore_cache:
          keys:
            - v1-dependencies-{{ checksum "package.json" }}
      - run: npm install
      - run: npm test
      - save_cache:
          paths:
            - node_modules
          key: v1-dependencies-{{ checksum "package.json" }}

  deploy:
    docker:
      - image: circleci/node:16
    steps:
      - checkout
      - run: npm install
      - run: npm run build
      - run: npm run deploy

workflows:
  version: 2
  test-and-deploy:
    jobs:
      - test
      - deploy:
          requires:
            - test
          filters:
            branches:
              only: main

Lessons Learned

Incremental is better than all-at-once: Gradual migration reduced risk
API-first enables flexibility: The API layer gave us freedom to iterate on the frontend
Keep the database: We preserved MySQL, which simplified migration significantly
Maintain the old system: We continued fixing critical bugs in PHP during migration
Performance matters: Users loved the speed improvements

Conclusion

Modernizing legacy systems is challenging but incredibly rewarding. The key is finding a migration path that delivers value incrementally while maintaining business continuity.

The PHP system at Big D Companies now has a modern React frontend, improved performance, and a maintainable codebase - all while keeping the business running smoothly throughout the transition.
